The ECS1100 Series is latest generation of cost-effective smart switches. The ECS1100 Series is designed for SMB and enterprise markets with complete solutions from 5 to 28 ports, including 802.3af/at/bt PoE options. The switches comply with the IEEE 802.3az Energy Efficient Ethernet standard and support IPv4 management features.
The ECS1100-5P is a fanless design PoE switch that supports up to 4 ports at 30 W to meet the increasing power demands of users. The ECS1100 Series offers complete PoE solutions from 120 W to 480 W. All the switches are rack mountable.
The ECS1100-10HP/28HP support 802.3bt PoE Type4 with Power Class 8, which means its maximum power from PSE to PD is up to 90 W.
The ECS1100-10HP/28HP also delivers a default 250/480 W of PoE power to support future IP cameras, IP video telephones, access points, and PoE computers.
24 x RJ-45 10/100/1000 Ports (PoE)
af/at/bt 480W
4 x 1G SFP Port
56 Gbps Switching Capacity
Support ecCLOUD
